Enabling Future e-Powertrain Development

This webinar focuses on the design of electric motors and will show how multiphysics simulation and optimization allow to innovate and reduce costs, while considering multiple design constraints. Spin Applicazioni Magnetiche, a company creating innovative solutions of rare earth free synchronous reluctance motors for various power levels and applications will present a practical use case, including a detailed comparison between simulation and test results, considering electromagnetic, thermal and vibration responses.

The path towards electrification requires significant investment, changes to technologies, development processes and even organizational structures. This introductory webinar will reveal Altair's simulation- and data-driven design tools to accelerate all electrification projects by helping to make good decisions early. The session will cover solutions for the design of the various parts of electric drive systems, from the battery to the wheels; while considering system integration and the architecture changes that must be made at vehicle level to build innovative energy efficient electric mobility solutions.

Learn how to reduce motor control code development time with Altair Embed and STMicroelectronics. Embed provides ready-to-use libraries for motor control strategies combined with a fast debugging capability. The visual environment uses block diagrams to design, simulate, analyze, and automatically generate efficient code that can be downloaded, executed, and validated directly on target hardware. Deep support for the on-chip peripherals of the STM32 family of 32-bit microcontrollers reduces errors and iterations while lowering costs.

In this workshop you will discover the key features and benefits of simulation- and data-driven development and representation of e-motors in eMotor Director. The holistic and multi-physical development of e-motors requires a new way of thinking and a new development strategy. At Altair, we meet this challenge with simulation and data-driven development. Simulation and optimization are key development tools to ensure that all technical requirements can be met at minimal cost and time.

This presentation introduces the co-simulation solution between Altair EDEM and MotionSolve which enables engineers to introduce realistic bulk material loads to their multi-body dynamics simulations.

The Mining industry faces a lot of challenges and remains under high pressure to control costs, improve operational efficiency as well as meeting stricter environmental regulations. Innovation and the use of technology play a key role in addressing these and in shaping the future of mining. This webinar will explore how simulation and advanced technologies such as digital twins, machine learning and Internet of things (IoT) can help mines increase productivity, reduce costs, and improve safety. You will hear from industry leaders and technical experts on how Altair’s solutions can be used for efficient development and operation.

The Mining industry faces a lot of challenges and remains under high pressure to control costs, improve operational efficiency as well as meeting stricter environmental regulations. Innovation and the use of technology play a key role in addressing these and in shaping the future of mining. This webinar will explore how simulation and advanced technologies such as digital twins, machine learning and Internet of things (IoT) can help mines increase productivity, reduce costs, and improve safety. You will hear from industry leaders and technical experts on how Altair’s solutions can be used for efficient development and operation.

The Mining industry faces a lot of challenges and remains under high pressure to control costs, improve operational efficiency as well as meeting stricter environmental regulations. Innovation and the use of technology play a key role in addressing these and in shaping the future of mining. This webinar will explore how simulation and advanced technologies such as digital twins, machine learning and Internet of things (IoT) can help mines increase productivity, reduce costs, and improve safety. You will hear from industry leaders and technical experts on how Altair’s solutions can be used for efficient development and operation.

Altair has collaborated with Startup India, Automotive Research Association of India (ARAI), Confederation of Indian Industry - CII, and IIT Madras Incubation Cell for Altair Start-up Challenge 2021 - For EVs. This is an initiative to create awareness of appropriate cutting-edge technologies, relevant processes, enable the start-ups to accomplish their goals of product development in a structured manner. This facilitates competency building and the development of competitive products.

Simulation-Driven Design of Synchronous Motors

Predesign Methodologies In Motor Development Projects

Purpose Driven Electric Motor Modeling for Multi-physics System Simulation

Whether you are looking to understand the dynamic properties of your whole Formula Student vehicle or the mechanism of a small assembly of parts, MotionSolve from Altair is the perfect tool for you, and available for free to all students and Formula Student teams. This presentation will show first-hand how MotionSolve can be used to rapidly optimise your workflows and better understand your designs, so that you can create a dynamically stable chassis that beats the competition.

Improving the ESL using Complete Vehicle Correlation In the previous webinar, the development of an ESL has been shown based on a complete vehicle simulation. In order to validate this new approach, a comprehensive correlation work has been performed. Using the dynamic distortion in all closure body openings as correlation criteria offer a unique possibility to increase the understanding of the load from both the engine and the wheel suspension. This webinar presents this correlation where a test vehicle is driven on different test tracks both in reality and virtually. Presenter: Jens Weber | CAE Engineer, CEVT

Two and Three Wheeler companies be it existing OEMs, new EV start-ups or others serving this segment want to shorten the product development time and get to market faster. Designing a new two/three wheeled vehicle addressing refined customer expectations requires performance to be at par with established norms when it comes to vehicle ride, handling, and durability. To address this need Altair developed a New Unified solution for simulating two and three wheeled vehicles as a part of the HyperWorks 2020 release. The solution is aimed at companies designing and manufacturing two and three wheeled vehicles with IC or Electric engines. The solution is beneficial to both, leaning and non-leaning vehicles and helps engineers predict vehicle dynamics & control, durability and ride and comfort of two and three wheeled vehicles.

ESL Development Based on Simulation - Application example The body stiffness has a major impact on the Squeak & Rattle performance of a car. Since the body structure of electrical/autonomous cars will differ clearly from traditional bodies, an enhanced requirement is needed to limit the distortion in the closure openings. This webinar presents a new approach of defining a requirement based on closure deformations using an equivalent static load (ESL), which considers both the reduction from a complete vehicle to a BIG and from a dynamic load to a static load. In addition, an example is shown how ESL can be used as input for body optimization. Presenter: Viktor Jonsson | CAE Engineer (Consultant), CEVT

A transformação digital na engenharia de produto tem modificado o mercado e é de extrema importância para que empresas criem e desenvolvam novas máquinas e equipamentos com a mais alta qualidade, em menor tempo e reduzindo custos. Pensando nisso, a Altair apresentará um webinar (workshop online) sobre Como acelerar o lançamento de novos implementos, máquinas agrícolas e equipamentos pesados. Neste encontro, mostramos como a simulação computacional é uma rápida solução de investigação e análise de desempenho, além da possibilidade de simular qualquer situação de operação, seja no campo, rodovia ou canteiro de obras.

The Marine Engineering and Shipbuilding Industry is becoming even more important in the connected world. The ability to accelerate turnaround time and reduce cost is becoming a key driver to success. The use of simulation technologies to improve design efficiency and reduce physical testing costs continues to be one of the best ways to address engineering challenges in the Marine industry.

This workshop will showcase a process-oriented multidisciplinary simulation environment to accurately analyse the performance of complex rotating machines. The participants would learn about multiple physics analysis of motors; including electromagnetics, structural, thermal, and fluid dynamics using highly automated modelling tasks, helping to drastically reduce the time spent creating finite element models and interpreting results. Unique solution by Altair for rotating machinery process takes setup to a solution, time from hours to minutes which allows engineer to try multiple design iterations in a short time and create a performance curve in the automated environment.

Simulation-Driven Innovation for e-Mobility with SRM university

Electromagnetic and Thermal Simulation of PMSM (IPM) Motor

Rated Torque Simulation of IPM Motor Using Altair Flux

The Aero Utility tools available under User Profile>Engineering Tools>Aerospace options enables Aerospace engineers with unique modelling capabilties required in building Aero models. In this Webinar, we will explore a few of those utilities viz Airframe meshing, Composites Material Orientations, Compare FE contents and so on.

Replacement of traditional combustion engines with an electric powertrain, bring electro-mechanical induced tonal and high-frequency whine noise. In addition, tire and aerodynamic turbulent noise become more prominent in the absence of a standard Internal Combustion Engine. Also, the perceived sound quality imposes a new set of challenges. This leads to completely new methods of NVH refinement, keeping the decades of research aside. As it is important to address these issues at the design and development stage, adopting the new simulation techniques to manage future NVH challenges in e-Mobility is of the prime challenge to the traditional NVH engineers. In this webinar, we shall discuss some of those key NVH challenges specific to electric vehicles and appropriate simulation processes to develop countermeasures.

Electric Vehicles (EV) are complex systems and need to be connected, automated, lighter & smarter all at once. This calls for systems engineering where different systems are seen whole instead of in silos. Experience e-Mobility Simulation using Altair Model-Based System simulation solutions with real-time motor controller implementation on HIL (Hardware in the loop) with the micro-controller. Its intuitive block diagram environment allows users to model and simulate continuous and discrete dynamical systems, mix signal-based, physical modeling and Co-simulation with electro-magnetic & multi-body dynamics. End to end system-level virtual simulation for complete e-Mobility is made possible.

Traction Motor play key role in the electric vehicle/hybrid electric vehicle (EV/HEV) development process. The design of a High-Performance e-Motor is a complex undertaking. Engineers have conflicting constraints to consider including efficiency, temperature, weight, size, and cost. To explore more ideas, better understand their designs and improve performance, Altair HyperWorks™ has a workflow to guide motor designers through an efficient process of Simulation-Driven Design. This analysis and optimization solution supports multi-disciplinary teamwork and reduces design times.

Webinar from Prof. Dr. D.W.J. Pulle

Learn about the special capabilities available for vehicle simulations (cars & trucks) with Altair MotionSolve™

Nowadays, it is more and more challenging to design an e-motor. Many constraints have to be fulfilled, including maximizing power using minimal size, considering thermal constraints, material and production costs, and of course reducing weight. In order to meet these constraints, a multifaceted solution is needed, leveraging physics tools in combination with optimization methods. This webinar will introduce Altair's e-motor design and optimization solutions in a step by step process. We will discuss pre-design, magnetic computation and thermal analysis and show how optimization methods can help to optimize weight and cost at each step of the process (especially the weight of magnets) . We’ll demonstrate how Design Of Experiments (DOEs) allows designers to run different types of optimization very quickly, which enables informed decisions at different stage of the design cycle.

Introducing electric traction in automotive brings new challenges for the design of electric machines. Nowadays designers have to consider increasing constraints like efficiency, temperature, weight, compactness, cost but also stricter regulations, while reducing time to market. Fortunatly, Altair proposes disruptive methodologies to make relevant choices in the early stage of the design, based on numerical simulation and optimization techniques. Once the machine has been selected and designed in Altair FluxTM this webinar covers how an electric motor design's performance is evaluated and maximized considering its global efficiency along the whole driving cycle. The next design challenge is to get an accurate estimation of the losses, which becomes more and more strategic in the design process in order to accelerated speed to market with balanced design and confidence. This estimation is also a key issue of thermal design. Therefore, the study of losses (in particular non-conventional losses) is crucial. Two methods are proposed to take the current wave form into account: by using an equivalent circuit model in Altair ActivateTM system modelling software, or by representing the PWM in Flux circuit context.

At Elaphe, the engineers have been facing the NVH challenges from the very beginning. The topology of this electric motor, which on the one hand enables the team to use the otherwise empty space inside the wheel, can on the other hand, result in some new and unexplored NVH challenges. The experience over the years has proven that NVH is a bottleneck in the design cycle of Elaphe's motors and this was the main motivation for a more automated and more user-friendly NVH simulation workflow. Within the NVH, noise radiation was the area Elaphe was most interested in.

Given EVs are gaining momentum and the recent Govt. of India’s strict localization norms in EVs to avail incentives, Altair announces a 3-part webinar series to introduce its powerful and most comprehensive industry solution set for E-mobility from concept till end use. Open to startups, OEM and supplier alike, we invite you to join our 3-part live webinar series. We will discuss the various challenges in EV systems and how Altair solutions play an important role in the design & development stage. Namely, how you can cut down development time and cost while improving your designs, how you can rapidly prototype your ideas, tame the complexities involved in a highly complex system and lots more. We will highlight some unique challenges for EVs specific to India and discuss how to address them.

Discover Altair SimLab's automated workflow for coupled electromagnetic and vibration analysis. SimLab uses Altair Flux for electromagnetic analysis and Altair OptiStruct for vibro-acoustic simulation.

Light-weight, low cost, compact, high efficiency are some of the many objectives and constraints that have to be considered when designing a rotating machine. To meet these various challenges it is necessary to take into account several physical aspects: - electromagnetic - structural - thermal This presentation shows how Altair HyperStudy can involve several Altair solvers to consider different requirements into a single optimization and will be illustrated through various examples.

Because of always more compact and high efficiency systems, temperature is a critical constraint in electric machine design. Depending on the design stage, different levels of modeling can be proposed: - 1D for fast pre-design, to - full 3D CFD models for the validation stage. This presentation shows, through a complete example how the Altair platform for innovation helps machine designers to manage temperature distribution and evolution.

In the early stage of the design of an electric machine, it is key to assess its potential in terms of global energy efficiency when submitted to specific duty cycles. This presentation will show how: - FluxMotor is able to extract efficiency maps in a very fast way. - FluxMotor can be coupled to Altair HyperStudy for design exploration and optimization studies, considering the efficiency over duty cycles as an objective function to be maximized.

Altair Flux is a leading finite element simulation software for electromagnetic modeling. Used for more than 35 years in industry worldwide, and based on the most advanced numerical techniques, Flux has become a reference for the high accuracy it delivers. Altair also recently introduced Altair FluxMotor, a new tool for the pre-design of electric machines. In a very intuitive interface, it allows defining a machine from templates, creating its winding, and characterizing its performance in a few clicks. In this webinar, discover all the new features in the latest versions of Flux and FluxMotor.

The electric motor design process can be long and tedious. Modern design tools enables designers to quickly evaluate and compare machine techinical-economic potential. Discover how FluxMotor can radically change the way machines are designed, through each stage and be able to use standard or customized parts, add windings easily and quickly attribute materials before computing its performance.

Flux is now fully part of HyperWorks and thanks to our flexible HyperWorks Units, users are now able to access even more tools that will help you to save time in your designs and enable powerful simulations. Flux embeds its own pre-preprocessing tools but designers sometimes need to deal with complex 3D geometries generated by their CAD team.

This webinar, hosted by IEEE, focuses on Motor Control using Embed
